Red-Black Tree revisited, deleting nodes

Posted by Jack Altiere on December 22nd, 2008

In my last article, I showed how I implemented a red-black tree in C#.  One key implementation feature that I left off was the ability to delete a node.  The rules for deletion proved to be a little trickier for me than insertion, but I got through it.  Before I get into the gritty details of delete, I should at least present the easy alternative.  Rather than pulling out nodes and rotating the tree as needed, you could implement a “soft delete”.    By this I mean marking a node as deleted, but leaving the tree structure intact.   If I were to go this route, I would add a boolean property to the RedBlackNode class to indicate that the node was deleted, and perhaps add an operation to the tree class to rebuild the tree if the number of deleted nodes got too big, something like NodeCount / 2.  When the tree was rebuilt, any node that is deleted would not be re-inserted.

This could be implemented fairly easily, and with none of the headache that actually removing the nodes would cause.

   1:  // The only change to the RedBlackNode class was to
   2:  // add this auto-property.
   3:  public Boolean IsDeleted { get; set; }
   4:
   5:  // These are changes/additions to the tree class
   6:  // This method must be modified to look at the status
   7:  // of the node
   8:  public bool Contains(T value)
   9:  {
  10:     if (IsEmpty)
  11:        return false;
  12:
  13:     var current = _rootNode;
  14:     while (current != null)
  15:     {
  16:        switch (value.CompareTo(current.NodeValue))
  17:        {
  18:           case -1:
  19:              current = current.LeftNode;
  20:              break;
  21:           case 1:
  22:              current = current.RightNode;
  23:              break;
  24:           default:
  25:              return !current.IsDeleted;
  26:        }
  27:     }
  28:
  29:     // The item wasn't found.
  30:     return false;
  31:  }
  32:
  33:  public void DeleteNode(T value)
  34:  {
  35:     // Can't delete from an empty tree.
  36:     if (IsEmpty)
  37:        return;
  38:
  39:     var current = _rootNode;
  40:     bool valid = true;
  41:     while (valid && current != null)
  42:     {
  43:        switch (value.CompareTo(current.NodeValue))
  44:        {
  45:           case -1:
  46:              current = current.LeftNode;
  47:              break;
  48:           case 1:
  49:              current = current.RightNode;
  50:              break;
  51:           default:
  52:              SoftDelete(current);
  53:              valid = false;
  54:              break;
  55:        }
  56:     }
  57:  }
  58:
  59:  private void SoftDelete(RedBlackNode current)
  60:  {
  61:     // Mark the node as deleted.
  62:     current.IsDeleted = true;
  63:     _deletedNodes++;
  64:     _nodeCount--;
  65:
  66:     // Trim the tree if needed.
  67:     if (_deletedNodes >= _nodeCount / 2)
  68:        CleanupTree();
  69:  }
  70:
  71:  private void CleanupTree()
  72:  {
  73:     // This will be a list of all non-deleted nodes used to rebuild the tree.
  74:     var validNodes = new List<RedBlackNode>();
  75:
  76:     // This is how I will make sure I visit every node.
  77:     var nodeQueue = new Queue<RedBlackNode>();
  78:     nodeQueue.Enqueue(_rootNode);
  79:
  80:     RedBlackNode current;
  81:     while(nodeQueue.Count > 0)
  82:     {
  83:        current = nodeQueue.Dequeue();
  84:        // First, add the children of this node to the queue.
  85:        if (current.LeftNode != null)
  86:           nodeQueue.Enqueue(current.LeftNode);
  87:
  88:        if (current.RightNode != null)
  89:           nodeQueue.Enqueue((current.RightNode));
  90:
  91:        // Add the node to the list of valid nodes if it has not been deleted.
  92:        if (!current.IsDeleted)
  93:           validNodes.Add(current);
  94:     }
  95:
  96:     // The queue is empty at this point, so we have visisted every node.
  97:     // Now we need to rebuild the tree.
  98:     _rootNode = null;
  99:     _nodeCount = 0;
 100:     _deletedNodes = 0;
 101:     foreach (var node in validNodes)
 102:        Insert(node.NodeValue);
 103:  }
 104:

You can download the red-black tree implementation using soft delete here.

The alternative to a soft delete is to actually remove the nodes from the tree when they are deleted, which forces us to validate the tree to make sure our rules for a red-black tree are not violated.  Deleting a node is more complex than inserting a node.  When we inserted a node, we made the inserted node red, so that we only had to deal with double red violations.  When a node is deleted, it can be either a red node or a black node.  When the node is black, we need to worry about fixing the black node count in the tree so that none of the rules are violated.  As a refresher, here were the rules for a red-black tree:

  1. A red-black tree is a binary search tree, so nodes can have at most 2 children, and any node in the left sub-tree is less than the parent node, while any node in the right sub-tree is greater than the parent node.
  2. Each node has a color (red or black) and a red node can only have black children. (it is valid for a black node to have black children)
  3. The number of black nodes from the root node to any leaf contains the same amount of black nodes.  This is referred to as the black node count of the tree.
  4. The root node is always black.

There are a lot of cases for deletion that need to be considered.  We’ll start with the easiest ones.  The easiest nodes to delete are the leaf nodes of the tree. (those with no children)  Even in this simple case there are several scenarios.  If the node you deleted is red, you can just remove it from the tree.  Since it’s red, the black node count will not be affected in any way, therefore we still have a valid red-black tree.  The first case we need to worry about is when we are deleting a black leaf node that has a black sibling (also a leaf node).  If we just remove our node, the black node count will be wrong for the tree.  This is illustrated in the picture below, where we are deleting the node 15.



When we remove the node from the tree, we have to color the sibling node red and the parent node black to keep the tree valid, otherwise the black count would not be correct.  The next scenario is when you are deleting a black leaf node, and the sibling node has 1 child.  In this case, rotation is going to be necessary to balance the tree, along with the re-coloring of nodes to keep the tree valid.

In this case, we are deleting node 5, but to make the tree valid we are going to have to rotate the nodes around the sibling, and color node 30 black.  When dealing with this case, we can use the rotation methods that we already developed for insertion to balance the tree.  The last case we have to worry about when deleting a black leaf node is when the sibling has 2 children.  It turns out that this case is identical to the first case, as shown here:

When determining the rotations, keep in mind that the last 2 cases also have inverses, so there are actually 4 ways that you can end up rotating nodes, depending on where the sibling is in the tree compared to the node being deleted.  The most complex case is when we are deleting a black node whose sibling is red with 2 black children, as seen here:



In this case we need to perform rotation to balance the tree, and we also need to recolor nodes.  In the situation where the sibling is red with 2 black children, we will often have to perform 2 or 3 rotations to balance the tree again, so this scenario is definitely the most complex.

Now we have covered all the cases when deleting a black leaf node, but what happens when we delete a node that has children?  The easy case is when we delete a black node that has a single red child.  In this case, we just move the child up and color it black, which makes the tree valid.  We can’t have a red node with a single child since that would break the our rules for a red-black tree. Either there would be 2 red nodes in a row, or the black node count would be off.

The last set of scenarios deal with deleting a node that has 2 children.  The first thing we need to understand when dealing with this situation is the concept of a successor node.  This is critical when deleting nodes from a binary search tree.  This node is the one with the closest value to the node in question that is greater than the node.  It is easily found in a binary search tree by taking the right child of the node, and then traversing down the left node as far as you can.  For example, in the tree below the successor node of the node 20 is the node 28, which is highlighted in green.



The basic concept for deleting a node with 2 children is to find the successor node, pretend that you are deleting that node, and then substituting the successor node in place of the node you deleted.  The good news about this is that deleting a successor node will give us a case that we have already dealt with, because the successor is either going to be a leaf node, or a node with a single red child.  For example, in the image above, to delete the node 20, we would find the successor, which is 28.  Although it’s green in the image, we know from our rules that this node must be a red node, so in effect we are just deleting a red leaf node, which is easy!  All we do in this case is replace node 20 with 28, keeping the color the same, and remove the leaf node, making the finished tree look like this:

This is the code I came up with to perform delete:

   1:  private void HardDelete(RedBlackNode current)
   2:  {
   3:     // Make sure we remember to adjust the nodecount.
   4:     _nodeCount --;
   5:
   6:     if (current.LeftNode != null && current.RightNode != null)
   7:     {
   8:        // Find the successor node, swap the value up the tree,
   9:        // and delete the successor.
  10:        var successor = FindSuccessor(current);
  11:        current.NodeValue = successor.NodeValue;
  12:        PerformHardDelete(successor);
  13:     }
  14:     else
  15:        PerformHardDelete(current);
  16:  }
  17:
  18:  private void PerformHardDelete(RedBlackNode current)
  19:  {
  20:     // The node has either no children or 1 child.
  21:     if (current.LeftNode == null && current.RightNode == null)
